Quick Details

  • Place of Origin: Jiangsu, China (Mainland)
  • Brand Name: IVECO 300kw generator
  • Model Number: PF-IV413
  • Output Type: AC Three Phase
  • Speed: 1500RPM / 1800 RPM
  • Frequency: 50Hz / 60 Hz
  • Rated Power: 375kVA / 300 kW
  • Rated Voltage: 380/220V, adjustable
  • Rated Current: 600A
  • iveco generator Type: Soundproof Canopy, Mobile, etc
  • Iveco generator color: White, Turquoise, Yellow, etc
  • 300kw generator engine: with Euro IVECO PFT motor
  • 300kw diesel generator alternator: Stamford, Leroy Somer, etc
  • Diesel generator Cooling: Water-Cooled
  • ATS (automatic transfer switch): Socomec, Yuye, etc
  • Control Panel: AMF, LED display
  • Controller: Comap, Deepsea, Smartgen, etc
  • Circuit Breaker: MCCB, ACB, Delixi, ABB, etc
  • Certifications: CE, ISO9001:2000

Packaging & Delivery

Packaging Details: PE film, plywood package for optional
Delivery Detail: 15 working days after receiving the 30% deposit
ABOUT OF OUR COMPANY:

300kW IVECO Diesel Generator specification:

1. SPECIFICATIONS OF GEN-SET
1.1Set ModelPF-IV412
1.2Prime at 50HZ, 40℃ ambient300KW 375KVA
1.3Standby at 50HZ, 40℃ ambient330KW 412KVA
1.4Rated Gen-set output230/400V  50Hz
1.5Rated Relative humidity≤ 60 %
1.6Dimension (L×W×H)3040×1000×1850mm
1.7Weight3260kg
1.8Fuel consumption 100% prime load83L/h
1.9Total heat radiated to ambient73KW
1.10Structure of Gen-set

The Gen-set adopt

 integrative

structure,

 engine is fix on high

strength steel basic frame,

 anti vibration instrument

between the engine and

 basic frame, cooling fan

have protecting cap, control

cabinet and circuit breaker

installed on Gen-set.

1.11Control system (Optional)

Basic control panel or

 Advanced control panel

 with automatically  start-up

 function and other function.

2. SPECIFICATIONS OF ENGINE
2.1Engine BrandEURO IVECO engine
2.2Engine ModelCURSOR13TE2A
2.3Governor/ClassElectrical
2.4Cylinder NO.6
2.5Engine buildLine
2.6Fuel spray patternPT direct injection
2.7start-up method24V, electric
2.8AspirationTurbocharged/Aftercooled
2.9Cooling mode

Radiator cooled

(enclose water)

2.10Bore and stroke140×152 mm
2.11Compression ratio14.0:1
2.12Displacement14L
2.13Engine Prime Power at 1500rpm343KWm
2.14Engine Standby Power at 1500rpm377KWm
2.15Battery capacity127A/hr
2.16Starting/Min temperature7℃
2.17Lubrication oil capacity37L
2.18Coolant  capacity  -  radiator and engine (40℃)63L
2.19Exhaust temp - full load prime492℃
2.20Exhaust gas flow - full load prime4772m3/h
2.21Exhaust gas back pressure max76mmHg
2.22Air flow - radiator (40℃  ambient)8.3 m  3/s
2.23Pusher fan head (duct allowance) 40℃13mmH 2O
2.24Air   intake  -  engine -  full load prime1751m3/h
2.25Standard Air intake temp25℃
2.26Fuel type

#0 Diesel

 (Natural temperature)

2.27Filter system

Adopt  whole  changeable

 lubricating  oil, fuel

  filter and air filter

2.28Exhaust system

Adopt  industrial  high

 efficiency  muffler

and ripple pipe

3. SPECIFICATIONS OF ALTENATOR
3.1Alternator ModelStamford/HCI444FS
3.2Alternator TypeA.C. Synchronous
3.3Rated Voltage230/400V
3.4Rated Frequency50HZ
3.5Rated speed1500 RPM
3.6Voltage regulation modeAuto
3.7Alternator voltage regulation±0.5%
3.8Exciting modeBrushless self exciting
3.9Power factor0.8 (lagging)
3.10Phase & wires3 phase 12 wires
3.11Rated currency548.5A
3.12Efficiency0.937
3.13Insulation classH
3.14Protection classIP23
3.15Single load step to NFPA110100%

IVECO 300KW generator Product Details







 Diesel generator sets workshop photos:






Product Certification

---------------------------------------------------------------------------------------------------------------------------------------------------

To get fast reply, please leave  Engine , Power , Voltage & other requirements below



inquiry on IVECO generator 300kw price Please kindly contact me:





Email;   tina"@"sxtpower.com



Skype:  yangtinala



Whats App/Mobile Phone:   +86-13960878138



We Chat ID:  95270293 or Scan my Barcode







Any inqurey will be highly appericiated
